CHAPTER2 PROFIBUS Unit
(27) Counter variable D definition ............................................... Code 011B
The counter variable D is set.
Command option
QWn+22
QWn+20 QWn+18 QWn+16
QWn+14 QWn+12
Counter value
Command response
IWm+22
IWm+20 IWm+18 IWm+16
IWm+14 IWm+12
(Details)
Counter value:
A value of 0 to 65535 can be specified.
(Example)
Transmission example 1:
200 is set to the counter variable D.
QWn+22
QWn+20 QWn+18 QWn+16
QWn+14 QWn+12
QWn+10
QWn+8
0000
0000 0000
0000
0000 00C8
0000 011B
Response example 1:
It is normally ended.
IWm+22
IWm+20 IWm+18 IWm+16
IWm+14 IWm+12
IWm+10
IWm+8
0000
0000 0000
0000
0000 0000
0000 0200
MEMO
MEMO
The counter variable D is a variable which can be set as desired by the user, and a
desired value of 0 to 65535 can be set.
