LUBRICATION
Repair
8-8 BY Service Manual
© 2009 Yanmar Marine International
REPAIR
Engine Lubrication System Components
Figure 8-5
Figure 8-5
1 – Engine Oil Cooler
2 – Oil Filter Housing
3 – Oil Pressure Sensor
4 – Oil Pressure Sensor Line
5 – Turbocharger Lubrication Supply Line
6 – Turbocharger
7 – Turbocharger Lubrication Return Line
8 – Oil Pump
9 – Oil Pickup and Screen
0006521
(
2
)
(
1
)
(
3
)
(
4
)
(
5
)
(
7
)
(
6
)
(
8
)
(
9
)
