Yanmar 6BY2 - Engine Outline Drawings; 4 BY2 (Inboard)

GENERAL SERVICE INFORMATION
Engine Outline Drawings
3-4 BY Service Manual
© 2009 Yanmar Marine International
ENGINE OUTLINE DRAWINGS
Note: All dimensions are metric. Contact Yanmar Marine for the most current drawings.
4BY2 (Inboard)
Figure 3-1
Figure 3-1
A
A
204
719 (28.3)
469 (18.46)240 (9.44)
709 (27.91)
332 (13.07)
848 (33.38)
608 (23.93)
732
54
(2.13)
278 (10.94)
287 (11.29)
286 (11.25) 286 (11.25)
572 (22.5)
366.5 (14.43)
15.5 (.61)
61.5
(.24)
893 (35.15)
Ansicht S VIEW S (C16)
Schnitt A-A SECTION A-A (B16)
SAE 20/40-26
S
0006537
