EtherNet/IP 3-14
Class F5h – TCP/IP Object
Attributes
Service Code No. (hex) Service Name
01 Get Attribute All
0E Get Attribute Single
10 Set Attribute Single
Instance ID Attribute Description Get Set Size Default Value
0
1 Object Software Revision X Word 1
2 Maximum Instance X - Word 1
1
1 Status X Long
Bit 0: Not configured
Bit 1: Configured
Bit 2~31: Reserved
2 Configuration Capability X Long
Bit 0: BootP Client
Bit 1: DHCP Client
Bit 2: DNS Client
Bit 3: DHCP-DNS update
Bit 4: Configuration Settable
Bit 5~31: Reserved
3 Configuration Control X X Long
Bit 0~3: Start up Configuration
Bit 4: DNS Enable
Bit 5~31: Reserved
4 Physical Link X - Struct Path (Word): EPATH
5 Interface Configuration X X Struct
IP Address (Long)
Subnet Mask (Long)
Gateway (Long)
Name Server 1 (Long)
Name Server 2 (Long)
Domain Name (String)
