EtherNet/IP 3-15
Class F6h - Ethernet Link Object
Attributes
Service Code No. (hex) Service Name
01 Get Attribute All
0E Get Attribute Single
10 Set Attribute Single
4C Get and Clear
Instance ID Attribute Description Get Set Size Default Value
0
1 Object Software Revision
X - Word 1
2 Maximum Instance
X Word 1
1
1 Interface Speed X Long 10
2 Interface Flags X Long
Bit 0: Link Status
Bit 1: 0: Half Duplex
1: Full Duplex
Bit 2 ~ 31: Reserved
3 Physical Address (MAC ID) X Array 6 Words Unique per assembly
6 Interface Control X X Struct
Control Bits: Word
Forced Int Speed: Word
