EtherNet/IP 3-16
Class 29h – Control Supervisor Object
Attributes
Note:
1
See Fault Code Conversions at the end of this section.
Service Code No. (hex) Service Name
0E Get Attribute Single
10 Set Attribute Single
05 RESET
Instance ID Attribute Description Get Set Size V7 Data
0 1 Object Software Revision X - Word 1
1
3h Run 1 (Forward Run) X X Byte Forward Run Command
4h Run 2 (Reverse Run) X X Byte Reverse Run Command
5h Net Control X X Byte
Net Control Command - Parameter n003
Set: 0 = previous n003 value
1 = n003 = 3
6h State X - Byte Inverter Status
7h Running 1 (Forward) X - Byte Forward Running
8h Running 2 (Reverse) X - Byte Reverse Running
9h Ready X - Byte Inverter Ready
10 (0Ah) Faulted X - Byte Inverter Fault
11 (0Bh) Warning X - Byte Inverter Alarm
12 (0Ch) Fault Reset X X Byte Fault Reset
13 (0Dh) Fault Code X - Word
Current Fault
1
14 (0Eh) Warn Code X - Word Current Warning
15 (0Fh) Control from Net X - Byte Net Control Status - Parameter n003
16 (10h) CIP Fault Mode X - Byte Always “2”
17 (11h) Force Fault X X Byte External Fault - EF0
18 (12h) Force Status X - Byte External Fault Status - EF0
