Parameter Tables 5-3
Class 79h, Instance 1 - Initialize/User Object
Instance ID 0 of each of the following tables is the Object Software Revision, Service GET, Data Type Word, 2 Bytes and Default Value 1.
Unless otherwise shown, all default values are 0. Table cells that do not contain a value either do not exist or are not available.
All parameters share the same service (GET/SET), data type (Word) and number of bytes (2).
Table 5.2 – Parameter Attribute
Parameter Description Attribute
n001 Initialization/Access Level 1
n002 Control Mode Select 2
n003 Run Command Select 3
n004 Frequency Reference 4
n005 Stopping Method 5
n006 Rev Run Prohibit 6
n007 Stop Key Select 7
n008 Local Frequency Select 8
n009 Frequency Ref Method 9
n010 Digital Oper Detect 10 (0Ah)
n011 Max Frequency 11 (0Bh)
n012 Max Voltage 12 (0Ch)
n013 Base Frequency 13 (0Dh)
n014 Mid Frequency 14 (0Eh)
n015 Mid Voltage 15 (0Fh)
n016 Min Frequency 16 (10h)
n017 Min Voltage 17 (11h)
n018 Accel/ Decel Units 18 (12h)
n019 Accel Time 1 19 (13h)
n020 Decel Time 1 20 (14h)
n021 Accel Time 2 21 (15h)
n022 Decel Time 2 22 (16h)
n023 S- Curve Sel 23 (17h)
n024 Frequency Reference 1 24 (18h)
n025 Frequency Reference 2 25 (19h)
n026 Frequency Reference 3 26 (1Ah)
n027 Frequency Reference 4 27 (1Bh)
n028 Frequency Reference 5 28 (1Ch)
n029 Frequency Reference 6 29 (1Dh)
n030 Frequency Reference 7 30 (1Eh)
n031 Frequency Reference 31 (1Fvh)
n032 Jog Reference 32 (20h)
n033 Freq Upper Limit 33 (21h)
n034 Freq Lower Limit 34 (22h)
n035 Display Mode 35 (23h)
n036 Motor Rated Current 36 (24h)
n037 Thermal Overload Sel 37 (25h)
n038 Thermal OL Time Const 38 (26h)
n039 Cooling Fan Sel 39 (27h)
n040 Motor Rotation 40 (28h)
n041 Accel Time 3 41 (29h)
