YASKAWA G7 - Page 61

61
Table 4.9 “F” Parameters
Access Level
Name Address Description Data Range Unit Default
During
Run
V/f
V/f
w/PG
OLV FV OLV2
0 During Run 1
1 Zero Speed
2 Fref/Fout Agree1
3 Fref/Set Agree 1
4 Frequency Detection 1
5 Frequency Detection 2
6 Inverter Ready
7 DC Bus Undervoltage
8 Baseblock 1
9 Option Reference
A Remote Operation
B Torque Detection 1 N.O.
C Frequency Reference Loss
D DB Overheat
E Fault
F Not Used
10 Minor Fault (Alarm)
11 Fault Reset Command Active
12 Timer Output
13 Fref/Fout Agree 2
14 Fref/Set Agree 2
15 Frequency Detection 3
16 Frequency Detection 4
17 Torque Detection 1 N.C.
18 Torque Detection 2 N.O.
19 Torque Detection 2 N.C.
1A Reverse Direction
1B Baseblock 2
1C Motor 2 Selected
1D Regenerating
1E Restart Enabled
1F Motor Overload (OL1)
20 OH Pre-alarm
37 During Run 2
F5-01 0399h
DO-02C/DO-08 Option Kit
Channel 1 Selection
38 drive Enable
1 0h - - - - -
F5-02 039Ah
DO-02C/DO-08
Channel 2 Selection
See F5-01 1 01h A A A A A
F5-03 039Bh DO-08 Channel 3 Selection See F5-01 1 02h A A A A A
F5-04 039Ch DO-08 Channel 4 Selection See F5-01 1 04h A A A A A
F5-05 039Dh DO-08 Channel 5 Selection See F5-01 1 06h A A A A A
F5-06 039Eh DO-08 Channel 6 Selection See F5-01 1 37h A A A A A
F5-07 039Fh DO-08 Channel 7 Selection See F5-01 1 0fh A A A A A
F5-08 03A0h DO-08 Channel 8 Selection See F5-01 1 0fh A A A A A
0 8 Channel Fixed
1 Binary Output
F5-09 03A1h DO-08 Selection
2
8 Channel Selectable
(F5-01 ~ F5-08)
1 0 A A A A A
0 Ramp to Stop
1 Coast to Stop
2 Fast-Stop (C1-09)
F6-01 03A2h
Communication Bus Fault
Selection (BUS)
3 Alarm Only
1 1 A A A A A
0 Always Detected
F6-02 03A3h EF0 Detection
1 Only During Run
1 0 A A A A A
0 Ramp to Stop
1 Coast to Stop
2 Fast-Stop (C1-09)
F6-03 03A4h EF0 Fault Selection
3 Alarm Only
1 1 A A A A A
