88
Table 5.1 User Parameter Settings
Parameter
Description Default User Setting Notes
H4-02 Terminal FM Gain 100.00 %
H4-03 Terminal FM Bias 0.00 %
H4-04 Terminal AM Selection 03h
H4-05 Terminal AM Gain 50.00 %
H4-06 Terminal AM Bias 0.00 %
H4-07 Terminal FM Signal Type 0
H4-08 Terminal AM Signal Type 0
H5-01 Modbus Node Address 1fh
H5-02 Baud Rate 3
H5-03 Parity Selection 0
H5-04 Communication Loss Response
3
H5-05 Communication Fault Selection
1
H5-06 Transmit Wait Time 5 ms
H5-07 RTS Control Selection 1
H5-10 Unit Selection for Register 0025h
0
H6-01 Terminal RP Selection 0
H6-02 Terminal RP Scaling 1440 Hz
H6-03 Terminal RP Gain 100.00 %
H6-04 Terminal RP Bias 0.00 %
H6-05 Terminal RP Filter Time 0.10 Sec
H6-06 Terminal MP Selection 02h
H6-07 Terminal MP Scaling 1440 Hz
L1-01 Motor Overload Fault Selection
1
L1-02 Motor Overload Time Constant
1.0 min
L1-03 Motor OH Alarm Selection 3
L1-04 Motor OH Fault Selection 1
L1-05 Motor Temperature Filter Time
0.20 Sec
L2-01 Power Loss Ride Thru Selection
0
L2-02 Power Loss Ride Thru Time 0.1 Sec
L2-03 Minimum Baseblock Time 0.5 Sec
L2-04 Voltage Recovery Ramp Time 0.3 Sec
L2-05 Undervoltage Detection Level kVA Dep.
L2-06 KEB Decel Time 0.0 Sec
L2-07 Power Loss Accel Time 0.0 Sec
L2-08 KEB Frequency Gain 100 %
L3-01 Stall Prevention Accel Selection
1
L3-02 Stall Prevention Accel Level 150 %
L3-03 Stall Accel Const HP Level 50 %
L3-04 Stall Prevention Decel Selection
1
L3-05 Stall Prevention Run Selection 1
L3-06 Stall Prevention Run Level 160 %
L3-11 Overvoltage Inhibit Selection 0
L3-12
Overvoltage Inhibit Voltage
Level
kVA Dep.
L4-01 Speed Agree Level 0.0 Hz
L4-02 Speed Agree Width 2.0 Hz
L4-03 Speed Agree Level +/- 0.0 Hz
L4-04 Speed Agree Width +/- 2.0 Hz
L4-05 Frequency Reference Loss Select
0
L4-06 Frequency Reference Loss Gain
80.00 %
L5-01 Number of Auto-Restarts 0
L5-02 Fault Selection During Restart 0
L6-01 Torque Detection 1 Selection 0
L6-02 Torque Detection 1 Level 150 %
L6-03 Torque Detection 1 Time 0.1 Sec
L6-04 Torque Detection 2 Selection 0
L6-05 Torque Detection 2 Level 150 %
L6-06 Torque Detection 2 Time 0.1 Sec
L7-01 Torque Limit Forward Motoring
200 %
