3 Electrical Installation
YASKAWA ELECTRIC TOEP C710616 38H YASKAWA AC Drive-L1000A Quick Start Guide 43
Electrical Installation
3
50077
R/L1, S/L2, T/L3 1/0 10 to 4/0
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 1 10 to 4/0
–, +1 – 2 to 4/0
+3 – 4 to 4/0
44
50099
R/L1, S/L2, T/L3 2/0 1 to 300
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 2/0 1 to 300
–, +1 – 2/0 to 3/0
+3 – 1 to 1/0
3 4 to 300
50130
R/L1, S/L2, T/L3 3/0 2/0 to 300
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 3/0 2/0 to 300
–, +1 – 3/0 to 4/0
+3 – 1/0 to 2/0
3 4 to 300
50172
R/L1, S/L2, T/L3 300 2/0 to 600
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 250 2/0 to 600
–, +1 – 2/0 to 400
+3 – 2/0 to 250 M10
18 to 23
(159 to 204)
1 1 to 350 M12
32 to 40
(283 to 354)
50200
R/L1, S/L2, T/L3 400 2/0 to 600
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 350 2/0 to 600
–, +1 – 2/0 to 500
+3 – 250 to 300 M10
18 to 23
(159 to 204)
1 1 to 350 M12
32 to 40
(283 to 354)
Model
CIMR-LU
Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
Nm (lb.in.)
