3 Electrical Installation
42 YASKAWA ELECTRIC TOEP C710616 38H YASKAWA AC Drive-L1000A Quick Start Guide
500010
R/L1, S/L2, T/L3 10 14 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 14 14 to 6
–, +1, +2 – 14 to 6
B1, B2 – 14 to 10
8 12 to 8 M5
2.0 to 2.5
(17.7 to 22.1)
50013
R/L1, S/L2, T/L3 10 10 to 6
M5
3.6 to 4.0
(31.8 to 35.4)
U/T1, V/T2, W/T3 10 10 to 6
–, +1, +2 – 10 to 6
B1, B2 – 10 to 8
2.7 to 3.0
(23.9 to 26.6)
8 12 to 8 M6
5.4 to 6.0
(47.8 to 53.1)
50017
R/L1, S/L2, T/L3 8 10 to 6
M5
3.6 to 4.0
(31.8 to 35.4)
U/T1, V/T2, W/T3 10 10 to 6
–, +1, +2 – 10 to 6
B1, B2 – 10 to 8
2.7 to 3.0
(23.9 to 26.6)
8 10 to 8 M6
5.4 to 6.0
(47.8 to 53.1)
50022
50027
R/L1, S/L2, T/L3 6 6 to 4
M6
5.4 to 6.0
(47.8 to 53.1)
U/T1, V/T2, W/T3 6 6 to 4
–, +1, +2 – 6 to 4
B1, B2 – 10 to 8 M5
2.7 to 3.0
(23.9 to 26.6)
6 10 to 6 M6
5.4 to 6.0
(47.8 to 53.1)
50032
R/L1, S/L2, T/L3 6 10 to 3
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3 6 10 to 3
–, +1 – 6 to 1
B1, B2 – 12 to 3
66
50041
R/L1, S/L2, T/L3 4 10 to 3
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2, W/T3 6 10 to 3
–, +1 – 6 to 1
B1, B2 – 8 to 3
66
50052
R/L1, S/L2, T/L3 4 10 to 4/0
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 4 10 to 4/0
–, +1 – 4 to 4/0
+3 – 6 to 4/0
44
50062
R/L1, S/L2, T/L3 3 10 to 4/0
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 3 10 to 4/0
–, +1 – 3 to 4/0
+3 – 6 to 4/0
44
Model
CIMR-LU
Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
Nm (lb.in.)
