YASKAWA MH180 - Page 103

Parts lists
11 - 103
Tab. 11-4: Parts list U-arm unit
4012 HW1303780-1 Shaft 1
4013 HW0302261-A Shaft 1
4014 HW0302262-B Shaft 1
4016 HW0100173-2 Housing 1
4017 HR32013XJ Bearing 1
4018 HW1303381-1 Gear 1
4019 HW0401505-1 Nut 1
4020 HW0303951-1 Gear 1
4021 M8 x 20 Screw 1
4022 2L-8 Washer 1
4023 M4 x 6 Screw 1
4024 M8 x 20 Screw 6
4025 2L-8 Washer 6
4026 PT1/8 Sealing plug 1
4027 HR32006XJ Bearing 2
4028 M8 x 95 Screw 16
4029 2L-8 Washer 16
4030 M5 x 12 Screw 6
4031 M12 x 35 Screw 18
4032 2H-12 Washer 18
4033 GS210 O-ring 1
4034 MSTM8-20 Pin 1
4035 HW0303948-1 Gear 1
4036 MSTH6-15 Pin 1
3012 HW1100592-1 Housing 1
No. DWG no. Designation Piece
