YASKAWA MH180 - Grease Filling the Main Axes

Maintenance and inspection
9 - 64
9.4.1 Grease filling the main axes
Figures the main axes
S-axis gear
L-axis gear
U-axis gear
Grease outlet opening
Grease inlet opening
PT3/8
PT1/4
PT1/8
PT3/8
PT1/8
PT3/8
1
2
