2 Hardware Specifications

2.1 External View of the J71GF11-T2 Board

2-1

HW1483854

2 Hardware Specifications

2.1 External View of the J71GF11-T2 Board

Number Name Description

1 Operation LEDs Display the operation status of the CC-Link IE Field

network board.

2 P1 Port 1 connector for the CC-Link IE Field network

connection

3 P2 Port 2 connector for the CC-Link IE Field network

connection

11/53
