2 Hardware Specifications
2.2 J71GF11-T2 Specifications
2-2
HW1483854
HW1483854
2.2 J71GF11-T2 Specifications
For the details of output error codes, refer to the following manual of
MITSUBISHI ELECTRIC Co., Ltd.
“CC-Link IE Field Network Interface Board User’s Manual (For SW1DNC-
CCIEF-B)”
Items Specifications
Interface to external
device
CC-Link IE Field
Board mounting
position
PCI Express slot in the YRC1000
Error indicator LED indicators
Number of
transmission I/O
points
Maximum number of I/O points
Input: 2048 Output: 2048
Maximum number of I/O registers
Input: 276 Output: 276 (*when allocate the maximum number, removing error code output
from 560 general purpose M-register of the YRC1000 system)
Error code output The error code generated last is output to the specified M-register.
(The clear operation is not executed for the error code. To clear the error code, turn the
power of the YRC1000 system OFF then back ON.)
Transient
Transmission
(communications of
messages etc.)
The YRC1000 system is not applicable.
CSP+
(CC-Link family
system profile)
The YRC1000 system is not applicable.
12/53
