Definition of Terms Used Often in This Manual
The MOTOMAN is the YASKAWA industrial robot product.
The MOTOMAN usually consists of the manipulator, the controller, the
programming pendant, and supply cables.
In this manual, the equipment is designated as follows.
Descriptions of the programming pendant keys, buttons, and displays are
shown as follows:
Description of the Operation Procedure
In the explanation of the operation procedure, the expression "Select • • • "
means that the cursor is moved to the object item and [SELECT] is
pressed, or that the item is directly selected by touching the screen.
Registered Trademark
In this manual, names of companies, corporations, or products are
trademarks, registered trademarks, or brand names for each company or
corporation. The indications of (R) and
TM
are omitted.
Equipment Manual Designation
YRC1000 controller YRC1000
YRC1000 programming pendant Programming pendant
Cable between the manipulator and the
controller
Manipulator cable
Equipment Manual Designation
Programming
Pendant
Character Keys
/Symbol Keys
The keys which have characters or its
symbol printed on them are denoted with [ ].
ex. [ENTER]
Axis Keys
/Numeric Keys
[Axis Key] and [Numeric Key] are generic
names for the keys for axis operation and
number input.
Keys pressed
simultaneously
When two keys are to be pressed
simultaneously, the keys are shown with a
“+” sign between them,
ex. [SHIFT]+[COORD]
Displays The menu displayed in the programming
pendant is denoted with { }.
ex. {JOB}
