10.4 Motion Parameter Details
10.4.2 Setting Parameter List
10-31
Settings for Connecting Inverters
OW0D
Input Data Option
Selection
Bit 0: Motor Speed
0: Disabled, 1: Enabled
When this bit is set to 1 (enabled), the output data option
Motor Speed (IW13) will be monitored when the
command Inverter Drive Control is executed.
Bit 1: Torque Reference
(U1-09)
0: Disabled, 1: Enabled
When this bit is set to 1 (enabled), the output data option
Torque Reference (IW14) will be monitored when
the command Inverter Drive Control is executed.
Bit 2: Encoder Count
0: Disabled, 1: Enabled
When this bit is set to 1 (enabled), the output data option
Encoder Count (IW15) will be monitored when the
command Inverter Drive Control is executed.
Bit 3: Frequency
Reference (U1-01)
0: Disabled, 1: Enabled
When this bit is set to 1 (enabled), the output data option
Frequency Reference (IW16) will be monitored
when the command Control Inverter Drive is executed.
Bit 4: Multi-function
Analog Input A2
0: Disabled, 1: Enabled
When this bit is set to 1 (enabled), the output data option
Multi-function Analog Input A2 (IW17) will be
monitored when the command Inverter Drive Control is
executed.
Bit 5: Main Bus Voltage
0: Disabled, 1: Enabled
When this bit is set to 1 (enabled), the output data option
Main Bus Voltage (IW18) will be monitored when
the command Inverter Drive Control is executed.
Bit 6: Alarm Code
0: Disabled, 1: Enabled
When this bit is set to 1 (enabled), the output data option
Alarm Code (IW19) will be monitored when the
command Inverter Drive Control is executed.
Bit 7: Warning Code
0: Disabled, 1: Enabled
When this bit is set to 1 (enabled), the output data option
Alarm Code (IW1A) will be monitored when the
command Inverter Drive Control is executed.
Bit 8
Reserved by the system
Bit 9: Multi-function
Analog Input A3
0: Disabled, 1: Enabled
When this bit is set to 1 (enabled), the output data option
Multi-function Analog Input A3 (IW1C) will be
monitored when the command Inverter Drive Control is
executed.
Bit A: Multi-function
Input Terminal
0: Disabled, 1: Enabled
When this bit is set to 1 (enabled), the output data option
Digital Input Terminal (IW1D) will be monitored
when the command Inverter Drive Control is executed.
Bit B: Multi-function
Analog Input A1
0: Disabled, 1: Enabled
When this bit is set to 1 (enabled), the output data option
Multi-function Analog Input A1 (IW1E) will be
monitored when the command Inverter Drive Control is
executed.
Bit C: Encoder Counter
(ch2)
0: Disabled, 1: Enabled
When this bit is set to 1 (enabled), the output data option
Encoder Counter (ch2) (IW1F) will be monitored
when the command Inverter Drive Control is executed.
Bits D to F
Reserved by the system
(cont’d)
