YASKAWA MP2000 Series User Manual

6.4 Motion Subcommand Details
6.4.5 Read Fixed Parameters (FIXPRM_RD)
6-109
Motion Commands
6.4.5 Read Fixed Parameters (FIXPRM_RD)
The FIXPRM_RD command reads the current value of the specified fixed parameter and stores the value in the Fixed
Parameter Monitor monitoring parameter.
( 1 ) Executing/Operating Procedure
1. Check to see if all the following conditions are satisfied.
2. Set OW0A to 5 to execute the FIXPRM_RD motion subcommand.
The FIXPRM_RD will read the specified fixed parameter’s current value and store the code in the monitoring
parameter.
IW0A will be 5 during command execution.
IW0B, bit 0 will turn ON during the command processing and will turn OFF when the command processing
has been completed.
3. Set OW0A to 0 to execute the NOP motion command and then complete the monitoring operation.
( 2 ) Related Parameters
[ a ] Setting Parameters
[ b ] Monitoring Parameters
R
No. Execution Conditions Confirmation Method
1 Motion subcommand execution has been completed. IW0A is 0 and IW0B, bit 0 is OFF.
Parameter Name Setting Contents SVR
OW0A Motion Subcommand
The Read Fixed Parameter subcommand is executed when this parameter
is set to 5.
OW5C Fixed Parameter Number
Set the parameter number of the fixed parameter to be read.
Parameter Name Monitoring Contents SVR
IW0A
Motion Subcommand
Response Code
Indicates the motion subcommand that is being executed.
The response code is 5 during FIXPRM_RD command execution.
IW0B
Bit 0
Command Execution
Flag
Always OFF during FIXPRM_RD command execution.
IW0B
Bit 3
Command Error
Completed Status
Turns ON if an error occurs during FIXPRM_RD command execution. Turns
OFF when another command is executed.
IW0B
Bit 8
Command Execution
Completed
Turns ON when FIXPRM_RD command execution has been completed.
IL56
Fixed Parameter
Monitor
Stores the data of the specified fixed parameter number.
R
R
R
R
R
R
R
