YASKAWA MP2000 Series User Manual

10.4 Motion Parameter Details
10.4.3 Monitoring Parameter List
10-41
Settings for Connecting Inverters
IW10
Status
Bit 0: ALM Alarm
0: No alarm
1: Alarm activated
Bit 1: WARNING Warning
0: No warning
1: Warning activated
Bit 2: CMDRDY
Command ready
0: Command busy
1: Command ready
Bit 3: BB OFS
Baseblock
0: Baseblock in effect
1: Baseblock canceled
Bit 4: PON
Power ON
0: Main power supply OFF
1: Main power supply ON
Bit 5: RUNX
During Running
0: Stopped
1: Running
Bit 6: OSP
Zero Speed
0: With speed
1: 0 (zero) speed
Bit 7: REV
Reverse Operation
0: Forward
1: Reverse
Bit 8: RESET
During Reset
0: No Error Reset signal input
1: Error Reset signal being input
Bit 9: AGREE
During Speed Coincident
0: Speed disagreed
1: Speed agreed
Bit A: INV_READY
Inverter Ready
0: Inverter not ready
1: Inverter ready
Bit B: OPE
OPE Error
0: No OPE error
1: OPE error occurred
Bit C: UV_R
Momentary/Power Cut
0: Momentary
1: Power cut
Bit D: REMOTE
Remote Operation
0: Local
1: Remote
Bits E and F
Reserved by the system
IW11
Output Frequency
Unit: According to n035 for VSminiV7, o1-03 for
Varispeed F7 and G7
IW12
Output Current
• For VSminiV7, Varispeed F7 and G7
Unit: 0.1 A or 0.01 A
• For A1000 and V1000
8192 = Inverter rated current
IW13
Motor Speed (Option)
Unit: Depends on n035 for VSminiV7, o1-03 for
Varispeed F7 and G7
IW14
Torque Reference (U1-09) (Option)
Unit: 0.1%
IW15
Encoder Count (Option)
Unit: pulse
IW16
Frequency Reference (U1-01) (Option)
Unit: Depends on n035 for VSminiV7, o1-03 for
Varispeed F7 and G7
IW17
Multi-function Analog Input A2 (Option)
Unit: 0.1%
IW18
Mai
n Bus Voltage (Option
)
Unit: 1 V
IW19
Alarm Code (Option)
IW1A
Alarm Code (Option)
IW1B
−
Reserved by the system
IW1C
Multi-function Analog Input A3 (Option)
Unit: 0.1%
(cont’d)
Register No. Name Contents
