2.3 Mounting/Removing SVB-01 Modules
2.3.2 Removing SVB-01 Modules for Replacement
2-11
Settings and Installation
4.
Pull out the SVB-01 Module.
While holding both the top and bottom of the Module, pull the Module out straight towards you. Hold the Mod-
ule by its edges and do not touch any components on the Module.
Place the Module in the bag provided with the initial shipment and store it in this bag.
A optional cover (JEPMC-OP2300) must be installed on the empty slot.
