12.2 Troubleshooting System Errors
12.2.4 System Register Configuration and Error Status
12-17
Troubleshooting
[ c ] MP2200 Machine Controller
* Racks 2 to 4 can be used only when using EXIOIF.
[ d ] MP2300 Machine Controller
Name Register No. Remarks
I/O Error Count SW00200
Number of I/O error occurrences
Number of Input Errors SW00201
Number of input error occurrences
Input Error Address SW00202
Address of the latest input error (IW register num-
ber)
Number of Output Errors SW00203
Number of output error occurrences
Output Error Address SW00204
Address of the latest output error (OW register
number)
Reserved for the system
SW00205
Not used.
SW00206
SW00207
I/O Error Status
SW00208 to SW00215
Not used.
SW00216 to SW00223
Reserved for the system
SW00224 to SW00228
Error status of slot 1 of rack 1
(Depends on the mounted module and error code.)
SW00229 to SW00239
Error status of slot 2 of rack 1
(Depends on the mounted module and error code.)
SW00240 to SW00247
Error status of slot 3 of rack 1
(Depends on the mounted module and error code.)
SW00248 to SW00255
Error status of slot 4 of rack 1
(Depends on the mounted module and error code.)
... ...
SW00496 to SW00503
Error status of slot 9 of rack 4
*
(Depends on the mounted module and error code.)
Name Register No. Remarks
I/O Error Count SW00200
Number of I/O error occurrences
Number of Input Errors SW00201
Number of input error occurrences
Input Error Address SW00202
Address of the latest input error (IW register num-
ber)
Number of Output Errors SW00203
Number of output error occurrences
Output Error Address SW00204
Address of the latest output error (OW register
number)
Reserved for the system
SW00205
Not used.
SW00206
SW00207
I/O Error Status
SW00208 to SW00215
Slot 0 error status
(Depends on the mounted module and error code)
SW00216 to SW00223
Reserved for the system
SW00224 to SW00231
Slot 1 error status
(Depends on the mounted module and error code.)
SW00232 to SW00239
Slot 2 error status
(Depends on the mounted module and error code.)
SW00240 to SW00247
Slot 3 error status
(Depends on the mounted module and error code.)
