12.2 Troubleshooting System Errors
12.2.4 System Register Configuration and Error Status
12-20
[ d ] 260IF-01 Module Error Status (Slot 3)
<Error Status Details>
( 8 ) Module Information
[ a ] MP2100 Machine Controller
Item Code Description
ST#n
0
Normal communication
1
Communication error at the station n (n = local station
number in slave mode)
ST#15SW00241
Error code (Station error = 1) Subslot No. (= 2)SW00240
(Bit No.) F 87 0




ST#0
ST#31SW00242 ST#16
ST#47SW00243 ST#32
ST#63SW00244 ST#48
Name Register No. Description
Module Information
SW00800
MP2100 ID (C180H)
SW00801
Reserved by the system
SW00802
CPU Software version (BCD)
SW00803
Number of subslots
(Version 2.45 or before: 0004H, Version 2.46 or later:
0007H)
SW00804
CPU Function Module ID (C110H)
SW00805
CPU Function Module status
SW00806
I/O Function Module ID (8070H)
SW00807
I/O Function Module status
SW00808
SVB Function Module ID (9112H)
SW00809
SVB Function Module status
SW00810
SVR Function Module ID (9210H)
SW00811
SVR Function Module status
SW00812 to SW00815
Reserved by the system
