Technical data
6 - 30
6.4.1 Components for Changing the Working Area
To change the working area of S-axis, the following components are required (see the
following figure).
Fig. 6-4: Components of the S-axis limit
3 screws M20 x 70 (strength category
12.9) and 3 x M20 washers
Pin
Limit stop (HW0307574-1)
1
2
3
1
3
2
