Parts lists
11 - 79
Tab. 11-1: S-axis drive
1050 HW9405047-1 Shaft 1
1051 HW9405304-* Adjusting washer *
1052 G85 O-ring 1
1053 HW9405048-1 Housing 1
1054 2H-8 Washer 8
1055 M8 x 25 Screw 8
1056 2H-5 Washer 7
1057 M5 x 16 Screw 7
1058 IRTW-72 Ring 2
1059 ISTW-35 Ring 2
1060 CIMR35-1 Adjusting washer 2
1061 6207ZZ Bearing 2
1062 HW0307656-1 Pinion 1
1063 HW9405051-1 Cover 1
1064 2H-5 Washer 7
1065 M5 x 16 Screw 7
1066 M12 x 20 Screw 1
1067 PT3/8 Set screw 1
1068 HW0314644-A Cover 1
1069 M8 x 25 Screw 2
1070 2H-8 Washer 2
1071 HW0471083-A Cooling fan 1
1072 A-33C Fan cover 1
1075 TA1-S10 Terminal 4
1076 M5X10 Screw 4
1077 HW0308464-1 Flange 1
1078 TC8511013 Oil seal 1
1079 HW0308465-1 Shaft 1
1080 HW0484457-A Screw 4
1081 M5 Washer 4
1082 CC-0613-10 Washer 8
No. DWG no. Description Pcs
