YASKAWA MPL300-J00 User Manual

Parts lists
11 - 85
Tab. 11-3: U-axis drive
3008 2H-6 Washer 1
3009 M6 x 20 Screw 9
3010 M6 x 15 Screw 8
3011 HW0400016-1 Shaft 1
3012 HW0400008-1 Cover 1
3013 HW0406931-1 Cover 1
3014 G85 O-ring 1
3015 HW0400015-1 Shaft 1
3016 HW0400012-* Spring *
3017 AG3512E1 Oil seal 2
3018 HR32011XJ Bearing 2
3019 M12 x 45 Screw 10
3020 M12 x 75 Screw 1
3021 2H-12 Washer 11
3022 HW0406922-1 Cover 3
3023 HW0406923-1 Washer 5
3024 HW0307641-1 Shaft 2
3027 HW0484003-A Bearing 3
3028 M10 x 30 Screw 8
3029 2H-10 Washer 8
3030 M10 x 25 Screw 5
3031 M10 x 50 Screw 8
3032 2H-10 Washer 13
3033 AG3217A4 Oil seal 3
3034 G75 O-ring 3
3035 MSTH6-10 Pin 2
3036 HW0200686-1 Joint 1
3037 HW0308095-1 Joint 1
3038 HW0101147-1 Housing 1
3039 HW0101148-1 U-arm 1
3041 HW0307566-1 Shaft 1
2002 HW0101144-1 L-arm 1
2003 HW0101146-1 Joint 1
2054 HW0308094-1 Joint 1
No. DWG no. Description Pcs
