5 Peripheral Devices
5.5.3 External Dimensions
5-20
(3)
Model: JUSP-JUBM100AA
12
460
440
(8)
6
10
(10)
80
100
20
15
425
(15)
4
105
(23)
2-6 Dia.
Cooling Fan
Air Flow
Nameplate
Air Flow
Unit: mm
Approx.Mass: 2.8 kg
(305)
12
460
10
100
80
±
0.5
4-M5 Screw Holes
Base Mounting
Unit Rear View
440
±
0.5 (Mounting Pitch)
(Mounting Pitch)
<Mounting Hole Diagram>
<Unit Mounted Diagram>
109
111
