5.2 AC Reactor
5-5
Peripheral Devices
5
5.2.2
External Dimensions
(1)
Model: X008017
(2)
Model: X008018
180
180 max.
6-terminals for
M6 screws
Nameplate
75
2.3
150
±
54
0
80
100
25
80 max.
50
4-mounting holes
for M6 bolts
Unit: mm
180
180 max.
75
2.3
150
±
54
5
80
100
25
80 max.
50
6-terminals for
M6 screws
4-mounting holes
for M6 bolts
Nameplate
Unit: mm
94
96
