YASKAWA UAK series User Manual

2 Compatible Devices
2.2.3 Σ-V-SD Driver
2-18
(2) Cable Specifications for 24-volt Control Power Supply (With loose leads at one end
and connects a Σ-V-SD driver to a 24-volt control power supply)
∗ Specify the cable length in  of the order number.
Example: JZSP-CNG00-01
-E (1 m)
(3) Cable Specifications for 24-volt Control Power Supply (With connectors on both
ends and connects two Σ-V-SD drivers)
∗1. Specify the cable length in  of the order number.
Example: JZSP-CNG01-A2
-E (0.2 m)
∗2. Use a cable with a length of 0.3 m for the CACP-JU45A3B converter.
(4) Cable Specifications for Local Bus Communications
(5) Cable Specifications for Terminating Resistor of the Local Bus
(6) Cable Specifications for Converter I/O Signals
∗ Specify the cable length in  of the order number.
Example: JZSP-CJI01-01
-E (1 m)
Items Specifications
Order No. * JZSP-CNG00--E
Cable Length 1 m, 2 m, 3 m
Cable and
Connector
Cable: UL1015 AWG14
Cable-end connector to driver: 175362-1 (PIN : 353717-2)
Items Specifications
Order No.
*1
JZSP-CNG01-A-E
Cable Length
*2
0.2 m or 0.3 m
Cable and
Connector
Cable: UL1015 AWG14
Connector: 175362-1 (PIN : 353717-2)
Connector manufacturer: Tyco Electronics Japan G.K.
Items Specifications
Order No. JUPIT-W6004-A5
Cable Length 0.5 m
Cable HRZFVV-ESB (20276)
Remarks
The total number of cables must equal to the total number of SERVOPACKs
used.
Items Specifications
Order No. JUPIT-W6024
Remarks Connect the terminating resistor only to the SERVOPACK on the far right.
Items Specifications
Order No. * JZSP-CJI01--E
Cable Length 1 m, 2 m, 3 m
Cable and
Connector
Cable: HP-SB/20276SR #28×6P
Cable-end connector for external device: 10114-6000EL (Crimping type)
Remarks Used for emergency stop and the MCONs.
