YASKAWA UAK series User Manual

3 Specifications and External Dimensions for Motors
3.1.2 Ratings and Specifications
3-4
(2) Winding Selection Motor
∗1. The 50% ED rating (S3) is for a 10 minute cycle consisting of 5 minutes of operation and 5 minutes stopped.
∗2. Available only for three-phase, 200 VAC models.
Item
Model: UAKBJ-C (200 V), -CE (400 V)
06 08 11 15 19 22
30
*2
50% ED Rating (S3)
*1
kW 5.5 7.5 11 15 18.5 22 30
Continuous Rating (S1) kW 3.7 5.5 7.5 11 15 18.5 20
Continuous Rated Torque Nxm 71 105 143 263 249 307 332
Base Speed
min
-1
500 400 575
Maximum Speed
min
-1
7000 6000 5000
Moment of Inertia
×10
-3
kgxm
2
69.0 69.0 89.0 231.0 231.0 266.0 398.0
Vibration V5 V10
Noise dB (A) 75 or less 80 or less
Cooling Method Totally enclosed, external fan cooled
Protection Class IP44 (IEC34-5)
Cooling Fan Motor
Equipped with thermostat (automatic reset)
200 V class: Three-phase 200 V 50/60 Hz, 220 V 50/60 Hz, 230 V
60 Hz
400 V class: Three-phase 400 V 50/60 Hz, 440 V 50/60 Hz, 460 V
60 Hz
Encoder (Magnetic)
Pulse encoder (1024 p/r) (standard)
Serial encoder (17-bit)
Overheating Protection NTC thermistor
Installation
Flange type: IM B5, IM V1 (output shaft from horizontal to vertically
down)
Foot-mounted type: IM B3 (installed on floor)
Overload Capacity 200% of continuous rated (S1) output for 10 s
Thermal Class F
Withstand Voltage
200 V class: 1500 VAC for one minute
400 V class: 1800 VAC for one minute
Insulation Resistance 500 V DC 10 MΩ min.
Ambient Temperature and Ambient Humidity 0 to 40°C, 95% RH or less (no condensation)
Altitude 1000 m or less
Bearing Lubrication Grease
Paint Color Munsell N1.5
Compliant Standards JIS, JEC
Applicable
SERVOPACK
CACR-JU
Three-phase, 200 VAC 028A 036A 065A 065A 084A 102A 125A
Three-phase, 400 VAC 014D 018D 033D 033D 042D 051D –
