YASKAWA UAK series User Manual

3.1 Spindle Motor
3-7
Specifications and External Dimensions for Motors
3
(2) Winding Selection Motors
Model
UAKBJ-
Output Characteristics Tor q ue Ch ar ac te ri st ic s
06C
High-speed winding High-speed winding
Low-speed winding Low-speed winding
08C
High-speed winding High-speed winding
Low-speed winding Low-speed winding
Motor speed (min
-1
)
Output (kW)
7.4ޓ10 second rating
70001500 5000
3.1
4.7
5.2
6000
5.5ޓ50㧑ED rating
3.7
Continuous rating
Motor speed (min
-1
)
Torque (N࡮m)
1500 5000 6000 7000
35.0
23.6
47.1ޓ10 second rating
Continuous rating
50㧑ED rating
Motor speed (min
-1
)
Output (kW)
3.7ޓContinuous rating
1500500
6.6ޓ10 second rating
5.5ޓ50㧑ED rating
Motor speed (min
-1
)
Torque (N࡮m)
500 1500
105
126ޓ10 second rating
50㧑ED rating
70.7
Continuous rating
Motor speed (min
-1
)
Output (kW)
11ޓ10 second rating
70001500 4700
4.7
6.4
7.3
6000
7.5ޓ50㧑ED rating
5.5ޓContinuous rating
Motor speed (min
-1
)
Torque (N࡮m)
1500 4700 6000 7000
47.8
35.0
70.0ޓ10 second rating
Continuous rating
50㧑ED rating
Motor speed (min
-1
)
Output (kW)
5.5ޓContinuous rating
1500500
9ޓ10 second rating
7.5ޓ50㧑ED rating
Motor speed (min
-1
)
Torque (N࡮m)
500 1500
143
172ޓ10 second rating
50㧑ED rating
105
Continuous rating
