Advanced Phone Features
101
3. Select Paging List from the pull-down list of Type.
4. Click Confirm to accept the change.
To configure paging list via phone user interface:
1. Press the paging list key when the phone is idle.
2. Press or to select a desired paging group.
The default tag is Empty if it is not configured before.
3. Press the Option soft key and then press the Edit soft key.
4. Enter the multicast IP address and port number (e.g., 224.5.6.20:10008) in the
Address field.
The valid multicast IP addresses range from 224.0.0.0 to 239.255.255.255.
5. Enter the group name in the Label field.
6. Press the Save soft key to accept the change.
7. Repeat steps 2 to 6, you can add more paging groups.
Paging list is configurable via web user interface at the path: Directory->Multicast IP.
