Advanced Phone Features
103
To configure multicast listening addresses via web user interface:
1. Click on Directory->Multicast IP.
2. Select the desired value from the pull-down list of Paging Barge.
3. Select the desired value from the pull-down list of Paging Priority Active.
4. Enter the multicast IP address(es) and port number (e.g., 224.5.6.20:10008) which
the phone listens to for incoming RTP multicast in the Listening Address field.
5. Enter the label in the Label field.
Label will appear on the LCD screen when receiving the multicast RTP stream.
6. Click Confirm to accept the change.
Note
To send RTP stream via a paging list key when the receiver’s phone is idle:
1. Press the paging list key when the phone is idle.
2. Press or to select the desired paging group.
3. Press or the Paging soft key to send RTP.
The phone sends RTP to a preconfigured multicast address (IP: Port).
Both the sender’s and receiver’s phones play a warning tone and the receiver
automatically answers the multicast RTP session in the speakerphone mode.
The priorities of listening addresses are predefined: 1 with the highest priority, 10 with the
lowest.
Multicast listening addresses are configurable via web user interface only.
