Yealink SIP-T31G Administrator's Guide

Phone Customization
242
File Type
File Name
(* represents any char-
acter)
Template File Description
Lang keyboard_lang.xml keyboard_lang.xml Configures the language of the keyboard.
Ime keyboard_ime_*.xml
keyboard_ime_en.xml
Configures the alternative characters for
English keyboard in alphabetic input
mode.
keyboard_ime_francais.xml
Configures the alternative characters for
French keyboard in alphabetic input
mode.
keyboard_ime_num.xml
Configures the alternative characters for
keyboard in numeric&symbolic input
mode.
Layout keyboard_layout_*.xml
keyboard_layout_1.xml
Configures the layout of English keyboard
in alphabetic input mode.
keyboard_layout_2.xml
Configures the layout of English or French
keyboard in numeric&symbolic input
mode.
keyboard_layout_fran-
cais.xml
Configures the layout of French keyboard
in alphabetic input mode.
Note: If you want to customize the existing input method files of the onscreen keyboard, you just need to upload the custom
files.
If you want to create a new language onscreen keyboard, you should upload all three types of input method files at
a time. For the example above, you should upload “keyboard_lang.xml”, “keyboard_ime_francais.xml” and “key-
board_layout_francais.xml” files at a time.
Lang File Elements and Attributes
The following table lists the elements and attributes you need to understand in the Lang file. We recommend that
you do not edit these elements and attributes.
Elements Attributes
Description
Lang Name Specify the display name of the language.
Ime Name
Specify the Ime file(s) that the language will use.
Note: One Ime file can be used by multiple languages. For example, the key-
board in numeric&symbolic input mode is almost the same for each lan-
guage, you can use the template file (keyboard_ime_num.xml) as the input
method file for multiple languages.
Customizing a Lang File
1.
Open the template file.
2.
Edit the corresponding string in the file.

Yealink SIP-T31G Specifications

General

Mounting kit	Yes
Number of handles included	1 pc(s)
Display diagonal	2.3 \
Display resolution	132 x 64 pixels
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Voice codecs	G.722, G.729, AGC, G.729A, AJB, PLC, G.711Mu, VAD, G.711a, G.723.1, G.726, iLBC, CNG, OPUS
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	3 W
Lines quantity	2 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	2
Sustainability certificates	RoHS, REACH
Networking standards	IEEE 802.3af, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Gray
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	189 mm
Width	188 mm
Height	162 mm
Package depth	210 mm
Package width	213 mm
Package height	103 mm
