Yealink SIP-T42G User Manual

Basic Call Feature
137
calls.
Paging Priority Active
The Paging Priority Active parameter decides how the phone handles incoming
multicast paging calls when there is already a multicast paging call on the phone. If
enabled, the phone will ignore incoming multicast paging calls with lower priorities,
otherwise, the phone will answer incoming multicast paging calls automatically and
place the previous multicast paging call on hold. If disabled, the phone will
automatically ignore all incoming multicast paging calls.
To configure multicast listening addresses via web user interface:
1. Click on Directory->Multicast IP.
2. Select the desired value from the pull-down list of Paging Barge.
3. Select the desired value from the pull-down list of Paging Priority Active.
4. Enter the multicast IP address(es) and port number (e.g., 224.5.6.20:10008) which
the phone listens to for incoming RTP multicast in the Listening Address field.
5. Enter the label in the Label field.
Label will appear on the LCD screen when receiving the multicast RTP stream.
6. Click Confirm to accept the change.
Note
The priorities of listening addresses are predefined: 1 with the highest priority, 10 with the
lowest.
Multicast listening addresses are configurable via web user interface only.

Yealink SIP-T42G Specifications

General

Power requirements	100-240V, DC 5V
Power over Ethernet (PoE)	Yes
Touchscreen	-
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Voice codecs	G.711, G.723, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Grey
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	175 mm
Width	212 mm
Height	189 mm
