This compact, portable wire feed welder offers versatile capa-
bilities, including MIG (GMAW), flux-cored (FCAW), stick weld-
ing (SMAW), and DC lift TIG welding (GTAW) on mild steel and
stainless steel.
MIG Welding requires shielding gas to protect the weld pool dur-
ing cooling, sourced locally based on the material. It's ideal for
thinner materials, providing a clean finish, particularly for auto-
motive body panels.
Self-Shielded Flux-Cored Welding eliminates the need for addi-
tional shielding gas, using flux additives in the wire to protect
the weld. It's effective for medium to thicker materials and
works well on painted or rusty surfaces, making it suitable for
outdoor use, though the finish may not be as refined as MIG
welding.
Stick Welding (SMAW) is portable and versatile, allowing for
welding in various positions. It's effective for thicker materials
and outdoor environments, accommodating various electrodes.
DC Lift TIG Welding (GTAW) requires a lift TIG torch with a gas
valve for optimal performance. It excels in high-quality, precise
welds on thin materials, providing excellent control. The ma-
chine lacks a built-in gas solenoid, requiring manual gas flow
management. The arc is initiated with a lift arc technique for
clean starts, enhancing efficiency and weld quality in precision
applications.
1. SAFETY
GMAW (MIG/MAG)
Gas Metal Arc Welding
SMAW(STICK)
Shielded Metal Arc Welding
GTAW(TIG)
Gas Tungsten Arc Welding
FCAW(INNERSHIELD OR OUTSHIELD)
Flux-Cored Arc Welding
SAFETY PRECAUTIONS
ELECTRIC SHOCK can kill.
Ÿ Do not touch electrically live parts such as
output terminals or internal wiring.
Ÿ Insulate yourself from the work and
ground.
Ÿ Always wear dry insulating gloves.
FUMES AND GASES
can be dangerous.
Ÿ Keep your head out of fumes.
Ÿ Use ventilation or exhaust to remove
fumes from breathing zone.
WELDING SPARKS
can cause fire or explosion
Read entire operation section before operating
the WIRE FEEDER WELDER.
Ÿ Keep flammable material away.
Ÿ Do not weld on closed containers.
ARC RAYS can burn eyes and skin.
Ÿ Wear eye, ear and body protection.
WARNING
Observe all safety information
throughout this manual.
COMMON WELDING ABBREVIATIONS
PRODUCT DESCRIPTION (PRODUCT CAPABILITIES)
- 6 -
