3.10.3 Flux-cored Welding Parameters Recommendation
To achieve optimal welding results, it’s crucial to select the appropriate settings for specific welding application. The table below
provides recommended voltage, wire diameter, and wire feed speed values for various materials. Adjusting these parameters based
on the material and wire type ensures efficient performance and high-quality welds.
Basic Flux-cored Welding Recommended Parameter Settings
Mode
Voltage
Material
Gas Type
Wire
Diameter
Parameter
Display
Thickness
24ga
22ga
20ga
18ga
16ga
14ga
1/8"
3/16"
1/4"
3/8"
2T/4T/
SPOT/
S4T
MIG
Gun
/Spool
Gun
220V
Steel
/
.030"(0.8mm)
WFS(IPM)
79~512
/
/
118
138
157
169
197
315
394
/
.030"(0.8mm)
Voltage(V)
13.8~20.6
/
/
13.8
14.2
15
16.5
16.5
18
19
/
.030"(0.8mm)
Amperage(A)
90~200
/
/
120
136
153
190
200
200
200
/
.035"(0.9mm)
WFS(IPM)
79~512
/
/
/
98
142
173
220
315
378
480
.035"(0.9mm)
Voltage(V)
15~20.5
/
/
/
15
15.9
16.6
18
18.5
19.2
20.5
.035"(0.9mm)
Amperage(A)
90~200A
/
/
/
105
140
166
196
200
200
200
.045"(1.2mm)
WFS(IPM)
79~276
/
/
/
/
/
79
130
177
197
236
.045"(1.2mm)
Voltage(V)
15.2~19.5
/
/
/
/
/
15.2
17
18.5
19
19.5
.045"(1.2mm)
Amperage(A)
90~153
/
/
/
/
/
90
130
170
190
200
110V
Steel
/
.024"(0.6mm)
WFS(IPM)
79~335
/
/
118
138
157
197
315
/
/
/
.030"(0.8mm)
Voltage(Vag)
13.8~18.2
/
/
13.8
14.2
15
16.5
18
/
/
/
.030"(0.8mm)
Ampere(A)
60~176
/
/
50
60
80
90
130
/
/
/
.035"(0.9mm)
WFS(IPM)
79~236
/
/
/
98
142
173
220
/
/
/
.035"(0.9mm)
Voltage(V)
15~18
/
/
/
15
15.9
16.6
18
/
/
/
.035"(0.9mm)
Amperage(A)
60~136
/
/
/
50
64
84
98
/
/
/
Note: these values serve as general guidelines, and actual welding performance may differ depending on variables such
as material condition, environmental factors, and specific requirements of project requirements.
3.11.1 Spool Gun Connections
3.11 Spool Gun Setup
This section provides instructions on connecting the welding machine and spool gun. The connection setup varies depending on the
welding process, such as MIG/MAG or Flux. The machine is compatible with the optional YesWelder LBT150 spool gun or any
compatible Euro-connect spool gun with two-pin control cable from other brand.
Connection for Spool Gun- MIG/MAG Welding (Pulse Off/Pulse On/Dual Pulse)
