7-57
IM AQ6370C-17EN
Remote Commands
1
2
3
4
5
6
7
8
App
Index
:CALCulate:PARameter[:CATegory]:DFB
Ld
Function Sets/queries parameters for the DFB-LD
analysis function.
Syntax
:CALCulate:PARameter[:CATegory]:DFB
Ld<wsp><item>,<paramater>,<data>
:CALCulate:PARameter[:CATegory]:DFB
Ld?<wsp><item>,<paramater>
<item> = Analytical item that sets parameter(s)
<parameter> = Parameter to be set
<data> = Setting data
<item> <parameter> <data>
SWIDth ALGO ENVelope|THResh|RMS|
PKRMs
TH <NRf>[DB]
TH2 <NRf>[DB]
K <NRf>
MFIT OFF|ON|0|1
MDIFf <NRf>[DB]
SMSR SMODe SMSR1|SMSR2|SMSR3|
SMSR4
SMASk <NRf>[M]
MDIFf <NRf>[DB]
RMS ALGO RMS|PKRMs
TH <NRf>[DB]
K <NRf>
MDIFf <NRf> [DB]
POWer SPAN <NRf>[M]
OSNR MDIFf <NRf>[DB]
NALGo AFIX|MFIX|ACENter|
MCENter|PIT|0|1|2|3|4
NARea <NRf>[M]
MARea <NRf>[M]
FALGo LINear|GAUSs|LORenz|
3RD|4TH|5TH|0|1|2|3|4|5
NBW <NRf>[M]
SPOWer PEAK|INTegral|0|1
IRANge <NRf>
Example
:CALCULATE:PARAMETER:
DFBLD SWIDTH,ALGO,THRESH
:CALCULATE:PARAMETER:DFBLD? SWIDTH,
ALGO -> THR
:CALCULATE:PARAMETER:DFBLD
SMSR,SMASK,0.5NM
:CALCULATE:PARAMETER:DFBLD?
SMSR,SMASK -> +5.00000000E-010
Explanation If a non-existing parameter is used for a
combination, an execution error occurs.
(such as combinations of SWIDth and
SMODe)
This is a sequential command.
:CALCulate:PARameter[:CATegory]:FILB
tm
Function Sets/queries parameters for the FILTER-BTM
analysis function.
Syntax
:CALCulate:PARameter[:CATegory]:FIL
Btm<wsp><item>,<paramater>,
<data>
:CALCulate:PARameter[:CATegory]:FIL
Btm?<wsp><item>,<paramater>
<item> = Analytical item that sets parameter(s)
<parameter> = Parameter to be set
<data> = Data to be set
<item> <parameter> <data>
BLEVel SW OFF|ON|0|1
BWAVelength SW OFF|ON|0|1
CWAVelength SW OFF|ON|0|1
ALGO PEAK|BOTTom
TH <NRf>[DB]
MDIFf <NRf>[DB]
NWIDth SW OFF|ON|0|1
ALGO PEAK|BOTTom
TH <NRf>[DB]
MDIFf <NRf>[DB]
XTALk SW OFF|ON|0|1
ALGO PEAK|BOTTom|
BLEVel|GRID
TH <NRf>[DB]
MDIFf <NRf>[DB]
CSPace <NRf>[M]
SARea <NRf>[M]
Example
:CALCULATE:PARAMETER:FILBTM
CWAVELENGTH,ALGO,BOTTOM
:CALCULATE:PARAMETER:FILBTM
CWAVELENGTH,ALGO -> BOTT
:CALCULATE:PARAMETER:FILBTM
XTALK,CSPACE,0.2NM
:CALCULATE:PARAMETER:FILBTM?
XTALK,CSPACEe -> +2.00000000E-010
Explanation If a non-existing parameter is used for a
combination, an execution error occurs
(a combination of CWAVelength and SARea,
etc.).
On the AQ6373/AQ6373B, the following data
parameter cannot be set.
GRID
This is a sequential command.
7.6 Instrument-Specific Commands
