:MMEMory:LOAD:ATRace
Function Loads the specified waveform files (all traces)
into traces.
Syntax :
MMEMory:LOAD:ATRace<wsp>
<”file name”> [,INTernal|EXTernal]
<"file name"> = Name of file to load
INTernal|EXTernal = Source drive for loading
Example:
MMEMORY:LOAD:ATRACE "test001.
csv",internal
Explanation This is a sequential command.
:MMEMory:LOAD:DLOGging
Function Loads the specified data logging file.
Syntax
:MMEMory:LOAD:DLOGging<wsp><"filena
me">[,INTernal|EXTernal]
<"filename"> = Name of the file to load
INTernal|EXTernal = Source drive to load from
Example
:MMEMORY:LOAD:DLOGGING "test001.
LG8",INTERNAL
Description • This command is invalid when data logging is
in progress.
• This is a sequential command.
• This command can be used on the AQ6370C/
AQ6370D/AQ6373B/AQ6375B.
:MMEMory:LOAD:MEMory
Function Loads a specified waveform file into a specified
memory.
Syntax
:MMEMory:LOAD:MEMory<wsp><integer>,
<"file name">[,INTernal|EXTernal]
<integer> = Number of the memory into which a
file is loaded
<"file name"> = Name of file to be loaded
INTernal| EXTernal = Drive of source file to load
Example
:MMEMORY:LOAD:MEMORY 1,"test001.
wv6"INTERNAL
Explanation This is a sequential command.
:MMEMory:LOAD:PROGram
Function Loads a specified program file into a specified
program number.
Syntax
:MMEMory:LOAD:PROGram<wsp><integer>
,<"file name">[,INTernal|EXTernal]
<trace name> = Number of the program into
which a file is loaded
<"file name"> = Name of a file to be loaded
INTernal|EXTernal = Drive of source file to be
loaded
Example
MMEMORY:LOAD:PROGRAM 1,"test001.
pg6",INTERNAL
Explanation This is a sequential command.
:MMEMory:LOAD:SETTing
Function Loads a specified setting file.
Syntax
:MMEMory:LOAD:SETTing<wsp><"file
name">[,INTernal|EXTernal]
<"file name"> = Name of a file to be loaded
INTernal|LOPpy = Drive of source file to be
loaded
Example
MMEMORY:LOAD:SETTING "test001.
st6",INTERNAL
Explanation This is a sequential command.
:MMEMory:LOAD:TEMPlate
Function Loads a specified template file.
Syntax
:MMEMory:LOAD:TEMPlate<wsp><tem
plate>,<"file name">[,INTernal|
EXTernal]
<template> = Template at the loading
destination (UPPER|LOWER|TARGET)
<"file name"> = Name of a file to be loaded
INTernal|EXTernal = Drive at the loading source
Example
:MMEMORY:LOAD:SETTING
UPPER,"test001.csv",INTERNAL
Explanation This is a sequential command.
:MMEMory:LOAD:TRACe
Function Loads a specified waveform file into a specified
trace.
Syntax
:MMEMory:LOAD:TRACe<wsp>
<trace name>,<"file name">
[,INTernal|EXTernal]
<trace name> = Trace to be loaded
<"file name"> = Name of file to be loaded
INTernal|EXTernal = Drive of source file to load
Example
:MMEMORY:LOAD:TRACE TRA,"test001.
wv6",INTERNAL
Explanation This is a sequential command.
:MMEMory:MDIRectory
Function Creates a new directory.
Syntax
:MMEMory:MDIRectory<wsp><"directory
name">[,INTernal|EXTernal]
<directory name> = Directory name to be
created
INTernal|EXTernal = Destination drive for
created directory
Example
:MMEMORY:MDIRECTORY
"sample2",INTERNAL
Explanation This is a sequential command.
:MMEMory:REMove
Function Readies the USB storage media for removal or
queries the readiness status.
Syntax
:MMEMory:REMove
:MMEMory:REMove?
Response 0 = Ready for removal
1 = Not ready
Example
:MMEMORY:REMOVE
:MMEMORY:REMOVE -> 1
