Type Variable Name Description
Analysis variables
On the AQ6373/AQ6373B, invalid variables
NFCHN Contains the number of channels detected in performing
EDFA-NF analysis.
NFWL(CH) Contains the center wavelength of channel CH used in
performing EDFA-NF analysis.
NFLVLI(CH) Contains the input signal level of channel CH used in
performing EDFA-NF analysis.
NFLVLO(CH) Contains the output signal level of channel CH used in
performing EDFA-NF analysis.
NFASELV(CH) Contains the ASE level of channel CH used in performing
EDFA-NF analysis.
NFGAIN(CH) Contains the gain of channel CH used in performing EDFA-
NF analysis.
NFNF(CH) Contains NF of channel CH used in performing EDFA-NF
analysis.
Only the AQ6373/AQ6373B, valid variables
DOMWL Dominant wavelength value is entered when measuring the
dominant wavelength.
XCOL The chromaticity coordinate value X is entered when
performing COLOR analysis.
YCOL The chromaticity coordinate value Y is entered when
performing COLOR analysis.
ZCOL The chromaticity coordinate value Z is entered when
performing COLOR analysis.
Program control
variables
M Contains loop counter data.
N Contains loop counter data.
F1 Contains a conditional judgment variable.
F2 Contains a conditional judgment variable.
CH Contains an element number variable used in accessing an
array variable (1 to 1024).
Temprate variables GONO Contains GONO judgment results
8.3 Program Function Commands
