TRACE
Program Command Description Instrument models on which the
command is valid, parameter
ranges, and supported variables.
ACTIVE TRACE # Sets trace # to active trace. #: A to G
DISPLAY # Sets trace # to display mode. #: A to G
BLANK # Sets trace # to invisible mode. #: A to G
WRITE # Sets trace # to write mode. #: A to G
FIX # Sets trace # to data-fixing mode. #: A to G
MAX HOLD # Sets trace # to max. value detection
mode.
#: A to G
MIN HOLD # Sets trace # to min. value detection
mode.
#: A to G
ROLL AVG # *** Sets trace # to sequential addition
averaging mode.
#: A to G, 2 to 100 (1 step)
C=A-B(LOG) Sets trace C to TRACE A-B
computation mode (LOG)
C=B-A(LOG) Sets trace C to TRACE B-A
computation mode (LOG)
C=A+B(LOG) Sets trace C to TRACE A+B
computation mode (LOG)
C=A+B(LIN) Sets trace C to TRACE A+B
computation mode (LIN)
C=A-B (LIN) Sets trace C to TRACE A-B
computation mode (LIN)
C=B-A(LIN) Sets trace C to TRACE B-A
computation mode (LIN)
C=1-k(A/B) k=*.**** Sets trace C to 1-k (TRACE A/B)
computation mode
1.0000 to 20000.0000
(0.0001 step)
C=1-k(B/A) k=*.**** Sets trace C to 1-k (TRACE B/A)
computation mode
1.0000 to 20000.0000
(0.0001 step))
F=C-D(LOG) Sets trace F to TRACE C-D
computation mode (LOG)
F=D-C(LOG) Sets trace F to TRACE D-C
computation mode (LOG)
F=C+D(LOG) Sets trace F to TRACE C+D
computation mode (LOG)
F=D-E(LOG) Sets trace F to TRACE D-E
computation mode (LOG)
F=E-D(LOG) Sets trace F to TRACE E-D
computation mode (LOG)
F=D+E(LOG) Sets trace F to TRACE D+E
computation mode (LOG)
F=C+D(LIN) Sets trace F to TRACE C+D
computation mode (LIN)
F=C-D(LIN) Sets trace F to TRACE C-D
computation mode (LIN)
F=D-C(LIN) Sets trace F to TRACE D-C
computation mode (LIN)
F=D+E(LIN) Sets trace F to TRACE D+E
computation mode (LIN)
F=D-E(LIN) Sets trace F to TRACE D-E
computation mode (LIN)
F=E-D(LIN) Sets trace F to TRACE E-D
computation mode (LIN)
G=C-F(LOG) Sets trace G to TRACE C-F
computation mode (LOG)
G=F-C(LOG) Sets trace G to TRACE F-C
computation mode (LOG)
G=C+F(LOG) Sets trace G to TRACE C+F
computation mode (LOG)
8.3 Program Function Commands
