Program Command Description Instrument models on which the
command is valid, parameter
ranges, and supported variables.
G=E-F(LOG) Sets trace G to TRACE E-F
computation mode (LOG)
G=F-E(LOG) Sets trace G to TRACE F-E
computation mode (LOG)
G=E+F(LOG) Sets trace G to TRACE E+F
computation mode (LOG)
G=C+F(LIN) Sets trace G to TRACE C+F
computation mode (LIN)
G=C-F(LIN) Sets trace G to TRACE C-F
computation mode (LIN)
G=F-C(LIN) Sets trace G to TRACE F-C
computation mode (LIN)
G=E+F(LIN) Sets trace G to TRACE E+F
computation mode (LIN)
G=E-F(LIN) Sets trace G to TRACE E-F
computation mode (LIN)
G=F-E(LIN) Sets trace G to TRACE F-E
computation mode (LIN)
G=NORM A Sets the normalizd data of trace A to
be displayed on trace G.
G=NORM B Sets the normalizd data of trace B to
be displayed on trace G.
G=NORM C Sets the normalizd data of trace C to
be displayed on trace G.
G=CURVE FIT A **dB Sets curve fit processed data from
TRACE A to be displayed on trace G.
0 to 99 (1 step)
G=CURVE FIT B **dB Sets curve fit processed data from
TRACE B to be displayed on trace G.
0 to 99 (1 step)
G=CURVE FIT C **dB Sets curve fit processed data from
TRACE C to be displayed on trace G.
0 to 99 (1 step)
G=CURVE FIT PEAK
A **dB
Sets peak fit processed data from
TRACE A to be displayed on trace G.
0 to 99 (1 step)
G=CURVE FIT PEAK
B **dB
Sets peak curve fit processed data
from race B to be displayed on trace G.
0 to 99 (1 step)
G=CURVE FIT PEAK
C **dB
Sets peak curve fit processed data
from trace C to be displayed on trace G.
0 to 99 (1 step)
G=MARKER FIT **dB Sets curve fit processed data from the
placed delta marker to be displayed
on trace G.
0 to 99 (1 step)
CVFIT OPERATION
AREA####
Sets the target range for calculation
when creating curve fit processed
data.
####: ALL/IN L1-L2/OUT L1-L2
CURVE FIT/CURVE
FIT PEAK ALGO ####
Sets the fitting function when creating
a fitting function.
####:GAUSS/LORENZ/ 3RD
POLY/4TH POLY/5TH POLY
TRACE #-># Copies data from TRACE of the variable
@ to TRACE of the variable @
#: A to G
TRACE # CLEAR Clears trace # data. #: A to G
ALL TRACE CLEAR Clears all trace data.
8.3 Program Function Commands
