YOKOGAWA AQ6370C

8-28
IM AQ6370C-17EN
ZOOM
Program Command Description Instrument models on which the
command is valid, parameter
ranges, and supported variables.
ZOOM CENTER WL
****.***nm
Sets the display scale’s center
wavelength.
AQ6370C/AQ6370D
600.000 to 1700.000 (0.001 step)
AQ6373/AQ6373B
350.000 to 1200.000 (0.001 step)
AQ6375/AQ6375B
1200.000 to 2400.000 (0.001 step)
ZOOM CENTER
@@@@@
Sets the value of variable
@@@@@ to the display scale
center wavelength
@@@@@: E
1
, G, H, I, J, K, O
1
,
P, Q, R, S, T
1
, U
1
, V
1
, X, Y, Z, WM,
W1, W2, W(CH), PKWL, MEANWL,
WDMWL(CH), NFWL(CH), WAM1,
WAM2, WAM3, WAM4
ZOOM CENTER FREQ
***.****THz
Sets the display scale’s center
frequency.
AQ6370C/AQ6370D
176.5000 to 500.0000 THz
(0.0001 step)
AQ6373/AQ6373B
250.0000 to 856.5000 THz
(0.0001 step)
AQ6375/AQ6375B
125.5000 to 2500.0000 THz
(0.0001 step)
ZOOM CENTER FREQ
@@@@@
Sets the value of variable
@@@@@ to the display scale
center frequency
AQ6370C/AQ6370D
@@@@@: E
1
, G, H, I, J, K, O
1
, P,
Q, R, S, T
1
, U
1
, V
1
, X, Y, Z, PKWL,
MEANWL, WDMWL(CH), NFWL(CH)
, WAM1, WAM2, WAM3, WAM4
ZOOM CENTER
WNUM****.**cm
-1
Sets the display scale’s center
wavenumber.(only for AQ6375/
AQ6375B)
4167.000 to 8333.000 cm
-1
(0.001 step)
ZOOM CENTER
WNUM@@@@@
Sets the value of variable
@@@@@ to the display scale
center wavenumber
@@@@@: E
1
, G, H, I, J, K, O
1
,
P, Q, R, S, T
1
, U
1
, V
1
, X, Y, Z, WM,
W1, W2, W(CH), S, X, Y, Z, WM,
W1, W2, W(CH), PKWL, MEANWL,
WDMWL(CH), NFWL(CH)
ZOOM SPAN WL ****.*nm Sets the display scale’s span. AQ6370C/AQ6370D
0.1 to 1100.0 nm (0.1 step)
AQ6373/AQ6373B
0.1 to 850.0 nm (0.1 step)
AQ6375/AQ6375B
0.1 to 1200.0 nm (0.1 step)
ZOOM SPAN WL
@@@@@
Sets the value of variable
@@@@@ to the display scale
span
@@@@@: E
1
, G, H, I, J, K, O
1
, P,
Q, R, S, T
1
, U
1
, V
1
, X, Y, Z, S, X, Y,
Z, W2-W1, SPWD, WAM2-WAM1,
WAM4-WAM3
ZOOM SPAN FREQ
***.**THz
Sets the display scale’s span. AQ6370C/AQ6370D
0.01 to 330.00 THz (0.01 step)
AQ6373/AQ6373B
0.01 to 610.00 THz (0.01 step)
AQ6375/AQ6375B
0.01 to 130.00 THz (0.01 step)
ZOOM SPAN FREQ
@@@@@
Sets the value of variable
@@@@@ to the display scale
span
AQ6370C/AQ6370D
@@@@@: E
1
, G, H, I, J, K, O
1
, P,
Q, R, S, T
1
, U
1
, V
1
, X, Y, Z, W2-W1,
SPWD, WAM2-WAM1, WAM4-WAM3
ZOOM SPAN WNUM
***.**cm
-1
Sets the display scale’s span. AQ6375/AQ6375B
0.5 to 4200.0 cm
-1
(0.1 step)
ZOOM SPAN WNUM
@@@@@
Sets the value of variable
@@@@@ to the display
scale span. (only for AQ6375/
AQ6375B)
@@@@@: G, H, I, J, K, P, Q, R, S, X,
Y, Z, W2-W1, SPWD
8.3 Program Function Commands
