ANALYSIS
For the AQ6373/AQ6373B, replace “WDM” with “OSNR(WDM)” for all commands that
start with “WDM.”
Example)WDMANALYSIS→OSNR(WDM)ANALYSIS
The following commands are not available.
All commands that start with “EDFA-NF”
The following commands are not available on the AQ6375 if the wavenumber markers
are set.
• All commands that start with “WDM”
• All commands that start with “EDFA-NF”
• All commands that start with “FILTER”
Program Command Description Instrument models on which the
command is valid, parameter
ranges, and supported variables.
SPEC WD THRESH
**.**dB
Performs a THRESH-based
spectrum width search according to
the specified threshold value
0.01 to 50.00 (0.01 step)
PARAM THRESHK
**.**
Sets the magnification for the
THRESH based spectrum width
search
1.00 to 10.00 (0.01 step)
PARAM THRESH
MODE FIT ###
Turns ON/OFF the function that sets
the marker to the peak of the mode
when performing a THRESH-based
spectrum width search.
###: ON/OFF
SPEC WD ENV **.**dB Performs an envelope-based
spectrum width search using the
specified threshold value
0.01 to 50.00 (0.01 step)
PARAM ENV TH2
**.**dB
Sets the cutoff value for the envelope-
based spectrum width search.
0.01 to 50.00 (0.01 step)
PARAM ENV K **.**dB Sets the cutoff value for the envelope-
based using the THRESH method.
1.00 to 10.00 (0.01 step)
SPEC WD RMS
**.**dB
Performs an RMS-based spectrum
width search according to a specified
threshold.
0.01 to 50.00 (0.01 step)
PARAM RMS K **.** Sets the magnification for an RMS-
based spectrum width search
1.00 to 10.00 (0.01 step)
SPEC WD PEAK RMS
**.**dB
Performs an RMS-based spectrum
width search according to a specified
threshold value
0.01 to 50.00 (0.01 step)
PARAM PEAK RMS
K**.**
Sets the magnification for a PEAK-
RMS-based spectrum width search
1.00 to 10.00 (0.01 step)
SPEC WD NOTCH
**.**dB
Measures the NOTCH width using a
specified threshold value
0.01 to 50.00 (0.01 step)
PARAM NOTCH K **.** Sets a magnification based on notch
width measurement
1.00 to 10.00 (0.01 step)
NOTCH FROM ###### Sets the reference for making notch
width measurements.
#####: PEAK/BOTTOM
SMSR * Sets the execution mode applied in
SMR measurement
1, 2, 3, 4
SMSR MASK ±**.**nm Sets a mask range close to the peak
during SMSR1 measurements
0.00 to 99.99 (0.01 step)
POWER Performs power analysis
POWER OFFSET
***.**dB
Sets a correction value in power
measurements
–10.00 to 10.00 (0.01 step)
DFB-LD ANALYSIS Performs analysis necessary for DFB-
LD.
FP-LD ANALYSIS Performs analysis necessary for FP-
LD.
LED ANALYSIS Performs analysis necessary for LED.
8.3 Program Function Commands
