PEAK SEARCH
Program Command Description Instrument models on which the
command is valid, parameter
ranges, and supported variables.
PEAK SEARCH Performs a peak search on the active
trace waveform
BOTTOM SEARCH Performs a bottom search on the
active trace waveform
NEXT SRCH Searches for the next peak/bottom
after the peak/bottom level of the
active trace waveform
NEXT SRCH RIGHT Searches for the peak/bottom to the
right of the peak/bottom marker of the
active trace waveform
NEXT SRCH LEFT Searches for the peak/bottom to the
left of the peak/bottom marker of the
active trace waveform
SET MARKER **** Sets fixed marker to the moving
marker **** position
1 to 1024 (1 step)
SET MARKER @ Sets the fixed marker of variable @
to the moving marker position
@: G, H, I, J, K, P, Q, R, S, X, Y, Z, S,
N, M
CLEAR MARKER **** Clears fixed marker ****. 1 to 1024 (1 step)
CLEAR MERKER @ Clears the fixed marker of variable @. @: G, H, I, J, K, P, Q, R, S, X, Y, Z, S,
N, M
ALL MARKER CLEAR Clears all markers from the screen.
AUTO SEARCH ### Selects ON/OFF of the peak/bottom
search function conducted each
sweep
###: ON/OFF
MODE DIFF **.**dB Sets the level difference of the mode
judgment criteria used for peak
search or waveform analysis.
0.01 to 50.00 (0.01 step)
SEARCH/ANA L1-L2
###
Selects ON/OFF for the analysis
function in the range surrounded by
line markers 1 and 2
###: ON/OFF
SEARCH/ANAZOOM
AREA ###
Selects ON/OFF for the
analysisFunction of the display scale
range
###: ON/OFF
SEARCH MODE
######
Sets the search mode AQ6370C/AQ6370D/AQ6373B/
AQ6375B
######: SINGLE/MULTI
MULTI SEARCH
THRESH **.**dB
Sets the multi search threshold AQ6370C/AQ6370D/AQ6373B/
AQ6375B
0.01: 99.99 (0.01 step)
MULTI SEARCH SORT
BY #####
Sets the multi search detection list
sort order
AQ6370C/AQ6370D/AQ6373B/
AQ6375B
#####: WL/LEVEL
8.3 Program Function Commands
