YOKOGAWA AQ6370C - Page 195

8-34
IM AQ6370C-17EN
Program Command Description Instrument models on which the
command is valid, parameter ranges,
and supported variables.
LINE
MARKER4****.***dB
Sets line marker 4 to a specified
level.
–139.90 to 159.90 (0.01 step)
LINE MARKER4
****.***dBm
Sets line marker 4 to a specified
level.
–210.00 to 50.00 (0.01 step)
LINE MARKER4
*.***##
Sets line marker 4 to a specified
level.
1.00pW to 1000mW
(1.00to9.99[pW,nW,μW,mW]:
0.01 step
10.0to99.9(100)[pW,nW,μW,(mW)]:
0.1 step
100to999[pW,nW,μW,mW]:
1 step)
##is,pW,nW,μW,mW(Selectoneof
the above)
LINE MARKER4 **.*** Sets line marker 4 to a specified
level.
0.00 to 2500.00 (0.01 step)
LINE
MARKER4@@@@@
Sets line marker 4 to the level
position of variable @@@@@
@@@@@: E
1
, G, H, I, J, K, O
1
, P, Q, R,
S, T
1
, U
1
, V
1
, X, Y, Z, LM, L1, L2, L(CH),
PKLVL, WDMLVL(CH), NFLVLI(CH),
NFLVLO(CH), NFASELV(CH), MKPWR
MARKER L1-L2-
>SPAN
Sets the range surrounded
by line markers 1 and 2 to the
measuring span.
MARKER L1-L2-
>ZOOM SPAN
Sets the range surrounded
by line markers 1 and 2 to the
display scale span.
LINE MARKER CLEAR Clears line markers on the
screen.
MARKER OFFSET
LIST
Displays the difference from the
moving marker.
MARKER SPACING
LIST
Displays a difference to a
neighboring marker.
MARKER AUTO
UPDATE ###
Makes the level position of a
fixed marker follow the active
trace waveform.
###: ON/OFF
MARKER UNIT nm Sets a wavelength marker value
to the wavelength display.
MARKER UNIT THz Sets a wavelength marker value
to the frequency display.
MARKER UNIT cm
-1
Sets a wavelength marker value
to the wavenumber displzay.
AQ6375
SEARCH/ANA L1-L2
###
Selects ON/OFF for the analysis
function in the range surrounded
by line markers 1 and 2
###: ON/OFF
SEARCH/ANAZOOM
AREA ###
Selects ON/OFF for the analysis
function of the display scale
range
###: ON/OFF
MARKER LIST PRINT Prints out multiple marker
values.
AQ6370C/AQ6373/AQ6375
1: Generalized variables E, O, T, U, and V are valid only for the AQ6370C/AQ6370D/
AQ6375B.
8.3 Program Function Commands
