YOKOGAWA AQ6370C

8-46
IM AQ6370C-17EN
ADVANCE
Program Command Description Instrument models on which the
command is valid, parameter
ranges, and supported variables.
TEMPLATE GO/NO GO ## Sets whether GO/NO-GO
judgment is made
###: ON/OFF
TEMPLATE DISPLAY ### Turns the template data
display ON/OFF. ON:
UPPER LINE=ONLOWER
LINE=ONTARGET LINE=ON
###: ON/OFF
TEMPLATE
DISPLAYUPPER ###
Sets ON/OFF of upper line
display.
###: ON/OFF
TEMPLATE
DISPLAYLOWER ###
Sets ON/OFF of lower line
display.
###: ON/OFF
TEMPLATE
DISPLAYTARGET ###
Sets ON/OFF of target line
display.
###: ON/OFF
TMPLATE TEST TYPE
UPPER
Sets if GO/NO-GO judgment at
the upper line is made.
TMPLATE TEST TYPE
LOWER
Sets if GO/NO-GO judgment at
the lower line is made.
TMPLATE TEST TYPE UP
& LOW
Sets if GO/NO-GO judgment
at the upper and lower lines is
made.
TMPLATE WL
SHIFT****.***nm
Sets the amount of wavelength
shift of the template.
–999.999 to 999.999 (0.001 step)
TEMPLATE LEVEL SHIFT
***.**dB
Sets the amount of level shift of
the template.
–99.99 to 99.99 (0.01 step)
DATA LOGGING
START
Starts data logging AQ6370C/AQ6370D/AQ6373B/
AQ6375B
DATA LOGGING
ITEM########
Sets the data logging source AQ6370C/AQ6370D/AQ6373B/
AQ6375B
########: WDM, PEAK, MULTI-
PEAK, DFBLD
DATA LOGGING
MODE####
Sets the data logging mode
(maximum channel mode or
maximum logging mode)
AQ6370C/AQ6370D/AQ6373B/
AQ6375B
####:
MODE1 (MAX 1024 ch, 2001 times),
MODE2 (MAX 256 ch, 10001 times)
DATA LOGGING
INTERVAL #######
Sets the measurement interval
of data logging
AQ6370C/AQ6370D/AQ6373B/
AQ6375B
####: SWEEP TIME, 1 sec, 2 sec,
5 sec, 10 sec, 30 sec, 1 min, 2 min,
5 min , 10 min
DATA LOGGING TEST
DURATION *******s
Sets the measurement duration
of data logging (in seconds)
AQ6370C/AQ6370D/AQ6373B/
AQ6375B
*******: 1 to 8639999 (1 step)
DATA LOGGING PEAK
TH TYPE###
Sets how the threshold for
detecting the data logging mode
(peak or bottom) is specified
AQ6370C/AQ6370D/AQ6373B/
AQ6375B
###: ABS, REL
DATA LOGGING
PEAK TH
(ABS)****.**dBm
Sets the threshold (absolute
value) for detecting the data
logging mode
AQ6370C/AQ6370D/AQ6373B/
AQ6375B
****.**: 20.00 to -100.00
DATA LOGGING
PEAK TH
(REL)**.**dB
Sets the threshold (relative
value) for detecting the data
logging mode
AQ6370C/AQ6370D/AQ6373B/
AQ6375B
**.**: 0.01 to 99.99
DATA LOGGING CH
MATCHING TH ±
*.**nm
Sets the threshold of the
channel-matchingwavelengthλ
for data logging
AQ6370C/AQ6370D/AQ6373B/
AQ6375B
*.**: 0.01 to 1.00
DATA LOGGING
MEMORY ########
Sets the temporary area for
saving waveform files of data
logging
AQ6370C/AQ6370D/AQ6373B/
AQ6375B
###: INTERNAL, EXTERNAL
DATA LOGGING
TRACE LOGGING ###
Sets whether waveforms will be
logged during data logging
AQ6370C/AQ6370D/AQ6373B/
AQ6375B
###: ON/OFF
8.3 Program Function Commands
