SYSTEM
The following commands are not available on the AQ6373/AQ6373B
All commands that start with “SYSTEM GRID”
The following commands are not available on the AQ6375/AQ6375B if the wavenumber
markers are set.
• All commands that start with “SYSTEM GRID”
• All commands that start with “CUSTOM GRID”
• All commands that start with “GRID REFERENCE”
Program Command Description Instrument models on which the
command is valid, parameter
ranges, and supported variables.
OPTICAL ALIGNMENT Aligns the optical axis of a
monochromator optical system.
EXT OPTICAL
ALIGNMENT
Aligns the optical axis of a
monochromator optical system
using the external light source.
AQ6370D without the reference
light source (-LO)
SELF WL CALIBRATION Sets the light source to be
wavelength calibrated for the
internal light source.
AQ6370C/AQ6370D/AQ6375/
AQ6375B
EXT WL CALIBRATION
****.***nm
Sets the light source to be
wavelength calibrated for the
external light source (laser type)
AQ6370C/AQ6370D
600.000 to 1700.000 (0.001 step)
AQ6373/AQ6373B
350.000 to 1200.000 (0.001 step)
AQ6375/AQ6375B
1200.000 to 2400.000 (0.001 step)
EXT-GAS
WLCALIBRATION
****.***nm
Sets the light source to be
wavelength calibrated for the
external light source (gas cell type)
AQ6370C/AQ6370D
600.000 to 1700.000 (0.001 step)
AQ6375/AQ6375B
1200.000 to 2400.000 (0.001 step)
EMIS LINE WL
CALIBRATION ****. *** nm
Sets the light source to be
wavelength calibrated for the
external light source
(emission line light source type)
AQ6373B
350.000 to 1200.000 (0.001 step)
WL SHIFT **.***nm Sets the amount of wavelength
shift.
–5.000 to 5,000 (0.001 step)
LEVEL SHIFT ***.***dB
SYSTEM GRID 200GHz
Sets the amount of level shift.Sets
system grid to a 200 GHz spacing
grid table.
–60.000 to 60,000 (0.001 step)
SYSTEM GRID 100GHz Sets system grid to a 100 GHz
spacing grid table.
SYSTEM GRID 50GHz Sets system grid to a 50 GHz
spacing grid table.
SYSTEM GRID 25GHz Sets system grid to a 25 GHz
spacing grid table.
SYSTEM GRID 12.5GHz Sets system grid to a 12.5 GHz
spacing grid table.
CUSTOM GRID STARTWL
****.****nm
Inputs the user grid table
startwavelength.
1000.0000 to 1700.0000
(0.0001 step)
CUSTOM GRID
STARTFREQ ***.****THz
Inputs the user grid table
startfrequency.
176.3486 to 299.7924 (0.0001 step)
CUSTOM GRID STOP WL
****.****nm
Inputs the user grid table
stopwavelength.
1000.0000 to 1700.0000
(0.0001 step)
CUSTOM GRID
STOPFREQ ***.****THz
Inputs the user grid table
stopfrequency.
176.3486 to 299.7924 (0.0001 step)
CUSTOM GRID SPACING
***.*GHz
Inputs the user grid table
gridspacing.
0.1 to 999.9 (0.1 step)
GRID REFERENCE WL
****.****nm
Inputs the reference wavelength
of the grid table.
AQ6370C/AQ6370D
1000.0000 to 1700.0000
(0.0001 step)
AQ6375/AQ6375B
1200.0000 to 2400.0000
(0.0001 step)
8.3 Program Function Commands
