YOKOGAWA AQ6370C User Manual

7-18
IM AQ6370C-17EN
ADVANCE
Function Control Command Remarks
TEMPLATE
GO/NO GO ON/OFF
:TRACe:TEMPlate:GONogo<wsp>OFF|ON|
0|1
TEMPLATE DISPLAY
UPPER LINE
DISPLAY ON/OFF
:TRACe:TEMPlate:DISPlay<wsp>UPPer,
OFF|ON|0|1
LOWER LINE
DISPLAY ON/OFF
:TRACe:TEMPlate:DISPlay<wsp>LOWer,
OFF|ON|0|1
TARGET LINE
DISPLAY ON/OFF
:TRACe:TEMPlate:DISPlay<wsp>TARGet
,OFF|ON|0|1
TYPE
UPPER
:TRACe:TEMPlate:TTYPe<wsp>UPPer
LOWER
:TRACe:TEMPlate:TTYPe<wsp>LOWer
UPPER & LOWER
:TRACe:TEMPlate:TTYPe<wsp>U&L
TEMPLATE EDIT
ALL DELETE
:TRACe:TEMPlate:DATA:ADELete
<wsp>UPPer|LOWer|TARGet
MODE ABS/REL
:TRACe:TEMPlate:DATA:MODE<wsp>UPPe
r|LOWer|TARGet, ABSolute|RELative
EXTRA POL TYPE
TYPE A
:TRACe:TEMPlate:DATA:ETYPe<wsp>
UPPer|LOWer|TARGet,A|1
TYPE B
:TRACe:TEMPlate:DATA:ETYPe<wsp>
UPPer|LOWer|TARGet,B|2
NONE
:TRACe:TEMPlate:DATA:ETYPe<wsp>
UPPer|LOWer|TARGet,NONE|0
TEMPLATE SHIFT
:TRACe:TEMPlate:LEVel:SHIFt
<wsp><NRf>
:TRACe:TEMPlate:WAVelength:
SHIFt<wsp><NRf>
DATA LOGGING
START/STOP
:APPLication:DLOGging:STATe
<wsp>STOP|STARt|0|1
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
SETUP
LOGGING PARAMETER
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
LOGGING ITEM
:APPLication:DLOGging:LPARameter:I
TEM<wsp>0|1|2|3
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
LOGGING MODE
:APPLication:DLOGging:LPARameter:L
MODe<wsp>1|2
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
MINIMUM
INTERVAL
:APPLication:DLOGging:LPARameter:I
NTerval<wsp><integer>[SEC]
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
TEST DURATION
:APPLication:DLOGging:LPARameter:T
DURation<wsp><integer>[sec]
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
PEAK THRESH
TYPE
:APPLication:DLOGging:LPARameter:P
DETect:TTYPe<wsp>ABSolute|RELative
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
THRESH(ABS)
:APPLication:DLOGging:LPARameter:P
DETect:ATHResh<NRf>[DBM]
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
THRESH(REL)
:APPLication:DLOGging:LPARameter:P
DETect:RTHResh<NRf>[DB]
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
CHMATCHINGλ
THRESH
:APPLication:DLOGging:LPARameter:M
THResh<wsp><NRf>[M]
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
TRACE LOGGING
:APPLication:DLOGging:LPARameter:T
LOGging<wsp>OFF|ON|0|1
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
DESTINATION
MEMORY
:APPLication:DLOGging:LPARameter:M
EMory<wsp>INTernal|EXTernal
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
LOGGING DATA
SAVE
:
MMEMory:STORe:DLOGging<wsp>
<"file name">[,INTernal|EXTernal]
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
LOGGING DATA
LOAD
:MMEMory:LOAD:DLOGging<wsp>
<"file name">[,INTernal|EXTernal]
AQ6370C/AQ6370D/
AQ6373B/AQ6375B
7.2 Table of Correspondence between Soft Keys and Remote Commands
