Item
Name
R/W
(*3)
Data range
Units
Position of
decimal point
Default value (*):
Indicated item
Description
Display unit (BRAIN) Display unit/BRAIN
D20 Total Execution
(TOTAL EXEC)
W Start
Stop
Preset Total
Preset Rev Total
Start Executes“Start”or“Stop”ofthe
totalizationfunction,orexecutes“Preset
Total”or“PresetRevTotal”.
D21 Ttl Set Val Lower
(TL SET VAL L)
W 0 to 999999 0 0 Sets the totalization preset value in the
lower 6 digits of the 8-digit totalized
value.
D22 Ttl Set Val Upper
(TL SET VAL U)
W 0 to 99 0 0 Sets the totalization preset value in the
upper 2 digits of the 8-digit totalized
value.
D23 Ttl Switch Lower
(TL SWITCH LO)
W 0 to 999999 0 0 Sets the totalization switch value in the
lower 6 digits of the 8-digit totalized
value.
D24 Ttl Switch Upper
(TL SWITCH UP)
W 0 to 99 0 0 Sets the totalization switch value in the
upper 2 digits of the 8- digits totalized
value.
D30 Ttl User Select
(TL USER SEL)
W No
Yes
No Selects whether or not special units are
used as totalized units.
D31 Ttl User Unit
(TL USER UNIT)
W 8 alphanumeric
characters
ALL SPACE Sets the special totalized units.
D60 —
(SELF CHECK)
R Good
Error
See Chapter 7.
E00 Pulse Set
(PULSE SET)
E10 Pulse Unit
(PULSE UNIT)
W n Unit/P
u Unit/P
m Unit/P
Unit/P
k Unit/P
M Unit/P
Pulse/s
Pulse/s (*) Selects the flow rate unit per one pulse
as used for pulse output. Linked with
B32.
E11 Pulse Scale
(PULSE SCALE)
W 0 to 32000 E10
(B32)
0 to 4 0 (*) Setstheowrateperonepulseasused
for pulse output. Linked with B33.
E12 Pulse Width
(PULSE WIDTH)
W 50% Duty
0.05 ms
0.1 ms
0.5 ms
1 ms
20 ms
33 ms
50 ms
100 ms
50% Duty Selects the pulse width for pulse output.
E13 Pulse Low Cut
(PULSE LOWCUT)
W 0 to 100 % 0 3 % Sets the range in vicinity of 0% within
which pulse output will be halted.
E20
(*1)
Pulse Active Mode
(PLS ACT MODE)
W Closed(On) Act
Open(Off) Act
Closed(On) Act Selects whether pulse output will be set
to“OnActive”or“OffActive.”
E60 —
(SELF CHECK)
R Good
Error
See Chapter 7.
F00 Status Function
(STATUS FUNC)
F10
(*1)
SO1 Function
(SO1 FUNCTION)
W No Function
Warning Output
Total Switch
H/L Alarm
HH/LL Alarm
Fwd/Rev Ranges
Auto 2 Ranges
Auto 3 Ranges
Auto 4 Ranges
Ext 2 Answer
Ext 3 Answer
Ext 4 Answer
No Function Selects function for the SO1 terminal
F11
(*1)
SO2 Function
(SO2 FUNCTION)
W No Function
Warning Output
Total Switch
H/L Alarm
HH/LL Alarm
Fwd/Rev Ranges
Auto 2 Ranges
Auto 3 Ranges
Auto 4 Ranges
Ext 2 Answer
Ext 3 Answer
Ext 4 Answer
No Function Selects function for the SO2 terminal
*1: Applicable for AXFA11 Remote Converter.
*3: R/W: R = Read only, W = Read and Write
<8. Parameter Summary>
70
IM 01E20A01-01EN
