YOKOGAWA AXFA14G User Manual

<8. Parameter Summary>
73
IM 01E20A01-01EN
Item
Name
R/W
(*3)
Data range
Units
Position of
decimal point
Default value (*):
Indicated item
Description
Display unit (BRAIN) Display unit/BRAIN
H11 Display Select2
(DISP SELECT2)
W Off
Flow Rate(%)
Flow Rate
Flow Rate(mA)
Flow Rate(Bar)
Forward Total
Reverse Total
Dif Total
Tag No
Adhesion Check
Communication
Off Selects content of the second line for
Display Mode. Linked with B41.
H12 Display Select3
(DISP SELECT3)
W
Same as H11
(Display Select2)
Off Selects content of the third line for
Display Mode. Linked with B42.
H20 Display Cycle
(DISP CYCLE)
W 200ms
400ms
1s
2s
4s
8s
400ms Selects the display cycle.
H30 Language
(LANGUAGE)
W English
Japanese
French
German
Italian
Spanish
English Selects the language used by the
display unit. Linked with B10.
H60 —
(SELF CHECK)
R Good
Error
See Chapter 7.
J00 Aux
(AUX)
J10 4-20mA Low Cut
(4-20 LOW CUT)
W 0 to 10 % 0 0 % Sets the range in vicinity of 0% within
which the current output will be 4 mA
J11 4-20mA Low Lmt
(4-20 LOW LMT)
W -20.0 to 100.0 % 1 -20.0 % Sets the low limit for current output
J12 4-20mA High Lmt
(4-20 HI LMT)
W 0.0 to 120.0 % 1 120.0 % Sets the high limit for current output
J20 Flow Direction
(FLOW DIRECT)
W Forward
Reverse
Forward Selectstheowdirection.
J21 Rate Limit
(RATE LIMIT)
W 0 to 10 % 0 5 % Sets the level to reduce output
uctuation.
J22 Dead Time
(DEAD TIME)
W 0 to 15 s 0 0 s Sets the dead time to reduce output
fluctuation.When“0”isset,ratelimit
function is not available.
J23 Pulsing Flow
(PULSING FLOW)
W No
Yes
No Selects whether pulsing flow is to be
supported.
J24 T/P Damp Select
(T/P DAMP SEL)
W Damping
No Damping
Damping Selects whether the flow rate value
obtained through damping calculation
for total/pulse or the instantaneous flow
rate value (no damping) for total/pulse is
to be used.
J30 Power Synch
(POWER SYNCH)
W No
Yes
Yes Selects whether or not the internal
frequency is to be synchronized with the
power supply frequency.
J31 Power Frequency
(POWER FREQ)
R/W 47.00 to 63.00 Hz 2 50.00 Displays the power-supply frequency
(forPowerSynch=“Yes”),orsetsthe
power-supply frequency (for Power
Synch=“No”).
J40 Memo 1
(MEMO 1)
W ASCII 16 characters ALL SPACE Memoeld
J41 Memo 2
(MEMO 2)
W ASCII 16 characters ALL SPACE Memoeld
J42 Memo 3
(MEMO 3)
W ASCII 16 characters ALL SPACE Memoeld
J50 Software Rev No
(SOFTWARE REV)
R — Software revision number
J60 —
(SELF CHECK)
R Good
Error
See Chapter 7.
K00 Diagnosis
(DIAGNOSIS)
K10 Adhesion Check
(ADHESION CHK)
W No
Yes
No Selects whether or not to perform
diagnosis of adhesion to the electrode.
K11 Adhesion Level1
(ADH LEVEL1)
W 0.00 to 100.00 MΩ 2 0.10 Sets the resistance value for adhesion
Level 1 to the electorode.
*3: R/W: R = Read only, W = Read and Write
Parameter Summary
8
